30038-4S Viper S 1000W 12V Micro Drum Anchor Winch Bundle Kit with 100m of 4mm Hi Spec Rope IP68 Submersible with 6m of 6mm Chain
Key Information:

  • Suits most boats 4m to 6.0 metres.
  • Compact winch body for small spaces - but still 1000W of power.
  • Includes 100mtrs of 4mm HiSpec UHMWPE rope (1550kg braking strain) pre-spliced to a 10mtr 8mm 3 strand shock cord attached to the 6mtrs of 6mm chain with a stainless steel shackle ready to use! (Total of 116m of rope/chain & shock cord)

Great value for money - just have a look at all the hardware and goodies included in this kit! (see the What's in the Box tab)

This model is physically smaller than most drum winches so it may fit where other winches cannot.
Note: The word Micro refers to its small overall physical size not its power - it has a very powerful 1000W motor fitted with a
316 Stainless Steel Marine Gearbox.

Viper “S” Series MICRO 1000W All Stainless Steel Submersible Winch Bundle.

  • One Of The World’s Most Powerful Winch For Its Size & now with 316 Stainless Steel Marine Gearbox.
  • IP68 Waterproof Certification and now includes an Emergency Manual Release Safety Feature.

Bundled with 100mtrs of 4mm HiSpec UHMWPE rope (1550kg braking strain) pre-spliced to a 10mtr 8mm 3 strand shock cord attached to the 6mtrs of 6mm chain with a stainless steel shackle ready to use! (Total of 116m of rope/chain & shock cord)

  • 1000 Watt Stainless Steel Submersible Electric Motor with IP68 Certifification
  • All New 316 Stainless Steel Marine Grade Worm Drive Gearbox
  • 28mm Solid S/S Shaft With 3 Support Bearings
  • 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
  • 360 Degree Motor Rotation 16 Different Positions
  • 1 Mtr of 3 B&S Tinned Copper Cable Fitted & Leak tested
  • Max fall rate: 45mtrs per minute
  • Max retrieval rate: 40mtrs per minute
  • Suits most boats 4m to 6.0 metres.
  • Weight: 15kgs

All you have to add is your own cabling or one of the pre assembled, tinned copper marine wiring looms and you will never have to break your back pulling up your anchor and chain again!

1 metre 3B&S cables are already attached to the motor and leak tested to a IP68 waterproof rating.

(Note This kit has the (better) blue rope 4mm Hi Spec Rope roll picture - not the cheaper double braid shown in the bundle group item picture.)

(991429)

What's in the Box?

  • New Viper "S" Series MICRO 1000 Submersible All Stainless Anchor Winch
  • 100mtrs Of 4mm 12 Plait Uhmwpe Hi Spec 3000 Rope & Chain Kit-1550kg B/Strain
  • Viper pro series anchor swivel small - 30001
  • Viper deluxe anchor roller small - 30009
  • 200amp reversing solenoid - 30020
  • LED illuminated marine rocker switch - 90021
  • Viper laser etched led illuminated switch cover - 90046
  • 100 amp flush mount circuit breaker with rubber seal - 30046
  • Single led switch stainless steel face plate - 30051
  • Combo led switch & circuit breaker s/s face plate - 30052
  • 5mm stainless steel sandwich plate
  • All fixing hardware
  • Installation notes & wiring diagram

Recommended Optional Extras (also shown in this category)

  • Premade Wiring loom - choice of two: up to 6mt boat or 8mt boat
  • Chain Sock
  • Fitment Kit (if fiting to an aluminium boat)

We can ship this product almost anywhere in Australia!

SKU 991429
Model # 30038-4S
Brand Viper
Shipping Weight 29.0000kg
Shipping Width 0.430m
Shipping Height 0.330m
Shipping Length 0.480m
Unit Of Measure Kit

Viper 5 Year performance warranty.
