30003-8 Viper Pro 1500W Winch Pro Series II Drum Anchor Winch Kit Bundle with 100m 8mm 3 Strand Premium Rope

The Viper 1500 is our fastest and most powerful drum winch in our range with an amazing fall rate of 55mtrs per minute!

All you have to add is your own cabling or one of our custom made Bell Marine tinned copper marine wiring looms and you will never have to break your back pulling up your anchor and chain again!

Features:

With unsurpassed Viper reliability, it has more torque than a conventional drum winch, 3 support bearings hugging a 1 piece 32mm solid stainless steel shaft and 90 degree welded housing bracket which closes up the gap between your drum (preventing rope jams) and does not require any additional guards.
Constructed from 8mm plate 316 marine grade stainless steel (hand polished to a mirror finish) & comes std a 5 YEAR Viper performance warranty.

  • Max fall rate: 50mtrs per minute
  • Max retrieval rate: 46mtrs per minute
  • Suit vessel length: 8 mtrs plus
  • Max load: 360kgs
  • Weight: 28kgs
  • Please note: 1 meter of 3 B&S Cable is already attached to the motor with cable joiners at the ends for ease of installation

All you have to add is your own cabling or the custom made pre assembled tinned copper marine wiring looms and you will never have to break your back pulling up your anchor and chain again!

(991437)

What's in the Box?

  • Viper Pro Series II 1500 anchor winch – 30003 supplied with 1 mtr 3 b&s power leads & joining connectors pressure tested & sealed
  • 100mtrs of 8mm 3 strand premium rope - 30026
  • Spliced to 10mtrs of 8mm Short Link Chain
  • Viper pro series anchor swivel large - 30019
  • Viper deluxe anchor roller large - 30002
  • 400amp reversing solenoid - 30024
  • Led illuminated marine rocker switch - 90021
  • Viper laser inscribed led illuminated switch cover - 90046
  • 135 amp flush mount circuit breaker with rubber seal - 30025
  • Single led switch stainless steel face plate - 30051
  • Combo led switch & circuit breaker s/s face plate - 30052
  • 5mm stainless steel sandwich plate
  • All fixing hardware
  • Installation notes & wiring diagram

Recommended Optional Extras (also shown in this category)

  • Premade Wiring loom -  use 991455 (30060) up to  9mt boats loom - can be customised.
  • Chain Sock
  • Fitment Kit (if fiting to an aluminium boat)
SKU 991437
Model # 30003-8
Brand Viper
Shipping Weight 19.0000kg
Shipping Width 0.380m
Shipping Height 0.380m
Shipping Length 0.530m
Unit Of Measure Kit

Viper 5 Year performance warranty.
