Mini Sized Circuit Breaker 255 Series Panel Mount 30A

Very compact size - just 56mm x 37mm overall.
This tiny single pole thermal circuit breaker external ignition protected & weatherproof.

CB255 Type III Ignition Protected Weatherproof Panel-Mount Manual Reset Circuit Breaker with “Push-to-Trip” Option and SEMS Nuts Installed, 32Vdc
Marine rated.

  • Switchable
  • Manual reset with 'Push to Trip'
  • Panel mount
  • Weatherproof.
  • Stainless hardware & studs.
  • Ideal for DC power systems in marine applications, trucks, buses & RVs.
  • Single Pole

(550668)

  • Type:Switchable
  • Current Rating:10A, 15A, 20A, 25A, 30A, 35A, 40A, 50A
  • Body:Thermoset plastic
  • Mount:Panel
  • Operating Temp:-40°C to 85°C
  • IP Rating:IP66
  • Approvals:SAE J553
  • Type:Switchable
  • Current Rating:10A, 15A, 20A, 25A, 30A, 35A, 40A, 50A
  • Body:Thermoset plastic
  • Mount:Panel
  • Operating Temp:-40°C to 85°C
  • IP Rating:IP66
  • Approvals:SAE J553









SKU 550668
Model # CB255-30
Brand Bussman
Artist / Author Ruth Cunningham
Shipping Weight 0.2200kg
Shipping Width 0.070m
Shipping Height 0.070m
Shipping Length 0.100m
Unit Of Measure Each
