BEP Battery Switch 4 Positon Mini Surface Mount (1-2 - Both) 200A 113557 - SUR 701S
Suits Single Engine with 2 Battery Banks 701S

The 701-S is the smallest battery selector switch on the market.
This battery switch offers a simple and economical way of separating two batteries.
Four position rotating switch provides off, Battery 1, Both and Battery 2 alternatives.
Removable rear cover insulates the rear terminals against any short circuits.
Removable side plates on four sides provide easy access for heavy duty battery cables.
Moulded in high temperature, fibre-reinforced plastics

Specifications:

  • Continuous rating: 200 amps DC
  • Intermittent rating: 300 amps DC
  • Cranking rating: 1000 amps DC for 10 seconds
  • Voltage rating: 48 volts DC maximum
  • Terminal stud size: 3 x 8mm





(991177)

SKU 991177
Model # 701S-SM
Barcode # 9319786238721
Brand BEP
Shipping Weight 0.6000kg
Shipping Width 0.100m
Shipping Height 0.100m
Shipping Length 0.100m
Unit Of Measure Each
